Encapsulated Module (2-36W)

Product Search >>
Part No. Image Power(W) Input Volt(Vac/dc) Output Volt(vdc) Isolation Volt(Vac/dc) Efficiency(%) Package Size(mm) Certificate/
Standards		 Datasheet
/3D		 Samples Request
FA3-220S3V3A2N3
85-265/120-380 3600/- 37.7*18.7*13.6
FA2-220S24N2
85-305/120-430 3000/- 33.8*22.2*15.3
FA2-220S12N2
85-305/120-430 3000/- 33.8*22.2*15.3
FA2-220S05N2
85-305/120-430 3000/- 33.8*22.2*15.3
FA2-220S3V3N2
85-305/120-430 3000/- 33.8*22.2*15.3
FA2-220SXXN2
85-305/120-430 3.3,5,12,24 3000/- 68,70,75,78 33.8*22.2*15.3 -,CE,UL,RoHS,FCC
FA3-220S3V8A2N3
85-265/120-380 3600/- 37.7*18.7*13.6
FA3-220SXXA2N3
85-265/120-380 3.3,3.8,5,9,12,13,15,24 3600/- 67,68,71,73,75,77 37.7*18.7*13.6 CE,RoHS
DA3-220S24G2N4
85-305/120-430 4000/- 37.0*24.5*18
DA3-220SXXG2N4
85-305/120-430 5,12,15,24 4000/- 71,74,75,81 37.0*24.5*18 CE
DA3-220S12G2N4
85-305/120-430 4000/- 37.0*24.5*18
DA3-220S05G2N4
85-305/120-430 4000/- 37.0*24.5*18
FA3-220S05A2N3
85-265/120-380 3600/- 37.7*18.7*13.6
FA3-220S09A2N3
85-265/120-380 3600/- 37.7*18.7*13.6
FA3-220S12A2N3
85-265/120-380 3600/- 37.7*18.7*13.6
FA3-220S13A2N3
85-265/120-380 3600/- 37.7*18.7*13.6
FA3-220S15A2N3
85-265/120-380 3600/- 37.7*18.7*13.6
FA3-220S24A2N3
85-265/120-380 3600/- 37.7*18.7*13.6
FA3-220SXXG2D4(-T)(-TS)
85-305/100-430 3.3,5,12,15,24 4000/- 68,70,74,76 25.4*25.4*17.6 -
FA3-220S3V3G2D4
85-305/100-430 4000/- 25.4*25.4*17.6
FA3-220S05G2D4
85-305/100-430 4000/- 25.4*25.4*17.6
FA3-220S12G2D4
85-305/100-430 4000/- 25.4*25.4*17.6
FA3-220S15G2D4
85-305/100-430 4000/- 25.4*25.4*17.6
FA3-220S24G2D4
85-305/100-430 4000/- 25.4*25.4*17.6
FA3-220SXXG2N3
85-265/120-380 5,12,24 3000/- 72,76,78 35.5*21.5*17.0 -
FA3-220S05G2N3
85-265/120-380 3000/- 35.5*21.5*17.0
FA3-220S12G2N3
85-265/120-380 3000/- 35.5*21.5*17.0
FA3-220S24G2N3
85-265/120-380 3000/- 35.5*21.5*17.0
FA3-300SXXY2N3(-T)(-TS)
90-528/100-745 5,12,15,24 3600/- 70,72,73,75 50.8*25.4*15.6 -
FA3-300S05Y2N3
90-528/100-745 3600/- 50.8*25.4*15.6
FA3-300S12Y2N3
90-528/100-745 3600/- 50.8*25.4*15.6
FA3-300S15Y2N3
90-528/100-745 3600/- 50.8*25.4*15.6
FA3-300S24Y2N3
90-528/100-745 3600/- 50.8*25.4*15.6
FA5-220S3V3C2D4
85-305/120-430 4000/- 48.5*36.0*20.5
DA3-220S15G2N4
85-305/120-430 4000/-
FA5-220S3V3G2D4
85-305/120-430 4000/- 25.4*25.4*17.6
FA5-220S3V3Y2D4
90-265/127-375 4000/- 50.8*25.4*15.16
FA5-220S3V3Y2N4
85-305/120-430 4000/- 50.8*25.4*15.16
DA5-220S12G2N4
85-305/120-430 4000/- 37.0*24.5*18
DA5-220S15G2N4
85-305/120-430 4000/- 37.0*24.5*18
DA5-220S24G2N4
85-305/120-430 4000/- 37.0*24.5*18
DA5-220SXXG2N4
85-305/120-430 5,12,15,24 4000/- 73,79,82 37.0*24.5*18 -
DA5-220S05G2N4
85-305/120-430 4000/- 37.0*24.5*18
FA5-220DXXC2N4
85-305/120-430 ±5,±12,±15,±24 4000/- 74,76,78,80 48.5*36.0*20.5 -
FA5-220D05C2N4
85-305/120-430 4000/- 48.5*36.0*20.5
FA5-220D12C2N4
85-305/120-430 4000/- 48.5*36.0*20.5
FA5-220D15C2N4
85-305/120-430 4000/- 48.5*36.0*20.5
FA5-220D24C2N4
85-305/120-430 4000/- 48.5*36.0*20.5
FA5-220E05XXC2N4
85-265/120-380 5,24 4000/- 74,77 48.5*36.0*20.5 -
FA5-220E0505C2N4
85-265/120-380 4000/- 48.5*36.0*20.5
FA5-220E0524C2N4
85-265/120-380 4000/- 48.5*36.0*20.5
FA5-220HXXXXXXC2N3
85-265/120-380 5,±5,±12,±24 3000/- 70,73,75 48.5*36.0*20.5 -
FA5-220H050505C2N3
85-265/120-380 4000/- 48.5*36.0*20.5
FA5-220H050505C2N3
85-265/120-380 4000/- 48.5*36.0*20.5
FA5-220H051212C2N3
85-265/120-380 4000/- 48.5*36.0*20.5
FA5-220H051212C2N3
85-265/120-380 4000/- 48.5*36.0*20.5
FA5-220H052424C2N3
85-265/120-380 4000/- 48.5*36.0*20.5
FA5-220H052424C2N3
85-265/120-380 4000/- 48.5*36.0*20.5
FA5-220SXXC2D4
85-305/120-430 3.3,5,9,12,15,24 4000/- 67,72,74,80,81 48.5*36.0*20.5 CE,RoHS
FA5-220S05C2D4
85-305/120-430 4000/- 48.5*36.0*20.5
FA5-220S09C2D4
85-305/120-430 4000/- 48.5*36.0*20.5
FA5-220S12C2D4
85-305/120-430 4000/- 48.5*36.0*20.5
FA5-220S15C2D4
85-305/120-430 4000/- 48.5*36.0*20.5
FA5-220S24C2D4
85-305/120-430 4000/- 48.5*36.0*20.5
FA5-220SXXG2D4(-T)(-TS)
85-305/120-430 3.3,5,12,12.5,15,24 4000/- 69,72,75,76,78 25.4*25.4*17.6 -,CE,CB,UL
FA5-220S05G2D4
85-305/120-430 4000/- 25.4*25.4*17.6
FA5-220S12G2D4
85-305/120-430 4000/- 25.4*25.4*17.6
FA5-220S12V5G2D4
85-305/120-430 4000/- 25.4*25.4*17.6
FA5-220S15G2D4
85-305/120-430 4000/- 25.4*25.4*17.6
FA5-220S24G2D4
85-305/120-430 4000/- 25.4*25.4*17.6
FA5-220SXXG2N3
85-265/120-380 5,12,24 3000/- 73,79,80 39.5*24.5*19.0 -
FA5-220S05G2N3
85-265/120-380 3000/- 39.5*24.5*19.0
FA5-220S12G2N3
85-265/120-380 3000/- 39.5*24.5*19.0
FA5-220S24G2N3
85-265/120-380 3000/- 39.5*24.5*19.0
FA5-220SXXY2D4
90-265/127-375 3.3,5,9,12,15,24 4000/- 69,71,74,78,79 50.8*25.4*15.16 CE
FA5-220S05Y2D4
90-265/127-375 4000/- 50.8*25.4*15.16
FA5-220S09Y2D4
90-265/127-375 4000/- 50.8*25.4*15.16
FA5-220S12Y2D4
90-265/127-375 4000/- 50.8*25.4*15.16
FA5-220S15Y2D4
90-265/127-375 4000/- 50.8*25.4*15.16
FA5-220S24Y2D4
90-265/127-375 4000/- 50.8*25.4*15.16
FA5-220SXXY2N4
85-305/120-430 3.3,5,12,15,24 4000/- 73,76,82,83,84 50.8*25.4*15.16 -
FA5-220S05Y2N4
85-305/120-430 4000/- 50.8*25.4*15.16
FA5-220S12Y2N4
85-305/120-430 4000/- 50.8*25.4*15.16
FA5-220S15Y2N4
85-305/120-430 4000/- 50.8*25.4*15.16
FA5-220S24Y2N4
85-305/120-430 4000/- 50.8*25.4*15.16
FA10-220S3V3E2D4
85-305/100-430 4000/- 55.0*45.0*21.0
FA5-220EXXXXC2D3
85-265/120-380 5 4000/- 77,78 48.50 x 36.00 x 20.50 -
FA5-220E0512C2D3
85-265/120-380 4000/-
FA5-220E0524C2D3
85-265/120-380 4000/-
FA6-220SXXD2
85-305/120-430 3.3,5,9,12,15,16.5,24 3750/- 71,75,78,80,82,84 39.0*25.0*22.0 CE,RoHS
FA6-220S3V3D2
85-305/120-430 3750/- 39.0*25.0*22.0
FA6-220S05D2
85-305/120-430 3750/- 39.0*25.0*22.0
FA6-220S09D2
85-305/120-430 3750/- 39.0*25.0*22.0
FA6-220S12D2
85-305/120-430 3750/- 39.0*25.0*22.0
FA6-220S15D2
85-305/120-430 3750/- 39.0*25.0*22.0
FA6-220S16V5D2
85-305/120-430 3750/- 39.0*25.0*22.0
FA6-220S24D2
85-305/120-430 3750/- 39.0*25.0*22.0
FA8-220S3V6D2
85-265/120-380 3000/- 39.0*25.0*22.0
FA8-220S3V8D2
85-265/120-380 3000/- 39.0*25.0*22.0
FA8-220S3V3D2
85-265/120-380 3000/- 39.0*25.0*22.0
