Part No. | Image | Power(W) | Input Volt(Vac/dc) | Output Volt(vdc) | Isolation Volt(Vac/dc) | Efficiency(%) | Package Size(mm) | Certificate/ Standards |
Datasheet /3D |
Samples Request |
---|---|---|---|---|---|---|---|---|---|---|
-/18-36 | -/1500 | 61.0*57.9*12.7 | ||||||||
ZBD75-24S12N-H | 75 | -/18-36 | -/1500 | 88 | 61.0*57.9*12.7 | - | ||||
ZBD75-24S12C-H | 75 | -/18-36 | -/1500 | 88 | 61.0*57.9*12.7 | - | ||||
ZBD75-24S12N | 75 | -/18-36 | -/1500 | 88 | 61.0*57.9*12.7 | - | ||||
ZBD75-24S12C | 75 | -/18-36 | -/1500 | 88 | 61.0*57.9*12.7 | - | ||||
-/9-36 | -/1500 | 61.0*57.9*12.7 | ||||||||
ZBD100-24S05AN-H | 100 | -/9-36 | -/1500 | 86 | 61.0*57.9*12.7 | - | ||||
ZBD100-24S05AC-H | 100 | -/9-36 | -/1500 | 86 | 61.0*57.9*12.7 | - | ||||
ZBD100-24S05AN | 100 | -/9-36 | -/1500 | 86 | 61.0*57.9*12.7 | - | ||||
ZBD100-24S05AC | 100 | -/9-36 | -/1500 | 86 | 61.0*57.9*12.7 | - | ||||
-/43-160 | -/3000 | 61.0*57.9*12.7 | ||||||||
ZBD150-110S12AN-H | 150 | -/43-160 | -/3000 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD150-110S12AC-H | 150 | -/43-160 | -/3000 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD150-110S12AN | 150 | -/43-160 | -/3000 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD150-110S12AC | 150 | -/43-160 | -/3000 | 91 | 61.0*57.9*12.7 | - | ||||
85-264/- | 3000/- | 61.0*57.9*13.7 | ||||||||
ZBA200-220S48 | 200 | 85-264/- | 3000/- | 86 | 61.0*57.9*13.7 | - | ||||
ZBA200-220S24 | 200 | 85-264/- | 3000/- | 85 | 61.0*57.9*13.7 | - | ||||
ZBA150-220S12 | 200 | 85-264/- | 3000/- | 84 | 61.0*57.9*13.7 | - | ||||
-/43-160 | 3000/- | 61.0*57.9*12.7 | ||||||||
ZBD200-110S05N-H | 200 | -/43-160 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD200-110S05C-H | 200 | -/43-160 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD200-110S05N | 200 | -/43-160 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD200-110S05C | 200 | -/43-160 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
85-264/- | 3000/- | 61.0*57.9*12.7 | ||||||||
ZBA200-220S28-H | 200 | 85-264/- | 3000/- | 85 | 61.0*57.9*12.7 | - | ||||
ZBA200-220S28 | 200 | 85-264/- | 3000/- | 85 | 61.0*57.9*12.7 | - | ||||
85-264/- | 2500/- | 61.0*57.9*12.7 | ||||||||
ZBA200-220S12-H | 200 | 85-264/- | 2500/- | 85 | 61.0*57.9*12.7 | - | ||||
ZBA200-220S12 | 200 | 85-264/- | 2500/- | 85 | 61.0*57.9*12.7 | - | ||||
85-264/- | 2500/- | 61.0*57.9*12.7 | ||||||||
85-264/- | 2500/- | 61.0*57.9*12.7 | ||||||||
-/18-75 | -/1500 | 61.0*57.9*12.7 | ||||||||
ZBD250-48S19N-H | 250 | -/18-75 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD250-48S19C-H | 250 | -/18-75 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD250-48S19N | 250 | -/18-75 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD250-48S19C | 250 | -/18-75 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
-/66-160 | -/3000 | 61.0*57.9*12.7 | ||||||||
ZBD250-110S48N-H | 250 | -/66-160 | -/3000 | 92 | 61.0*57.9*12.7 | - | ||||
ZBD250-110S48C-H | 250 | -/66-160 | -/3000 | 92 | 61.0*57.9*12.7 | - | ||||
ZBD250-110S48N | 250 | -/66-160 | -/3000 | 92 | 61.0*57.9*12.7 | - | ||||
ZBD250-110S48C | 250 | -/66-160 | -/3000 | 92 | 61.0*57.9*12.7 | - | ||||
-/185-400 | 3000/- | 61.0*57.9*12.7 | ||||||||
ZBD250-280S12N-H | 250 | -/185-400 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD250-280S12C-H | 250 | -/185-400 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD250-280S12N | 250 | -/185-400 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD250-280S12C | 250 | -/185-400 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
-/185-400 | 3000/- | 61.0*57.9*12.7 | ||||||||
ZBD250-280S15N-H | 250 | -/185-400 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD250-280S15C-H | 250 | -/185-400 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD250-280S15N | 250 | -/185-400 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD250-280S15C | 250 | -/185-400 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
-/185-400 | 3000/- | 61.0*57.9*12.7 | ||||||||
ZBD250-280S24N-H | 250 | -/185-400 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
ZBD250-280S24C-H | 250 | -/185-400 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
ZBD250-280S24N | 250 | -/185-400 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
ZBD250-280S24C | 250 | -/185-400 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
-/16-40 | -/1500 | 61.0*57.9*12.7 | ||||||||
ZBD300-24S12N-H | 300 | -/16-40 | -/1500 | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-24S12C-H | 300 | -/16-40 | -/1500 | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-24S12N | 300 | -/16-40 | -/1500 | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-24S12C | 300 | -/16-40 | -/1500 | 89 | 61.0*57.9*12.7 | - | ||||
-/9-40 | -/1500 | 61.0*57.9*12.7 | ||||||||
ZBD300-24S12AN-H | 300 | -/9-40 | -/1500 | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-24S12AC-H | 300 | -/9-40 | -/1500 | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-24S12AN | 300 | -/9-40 | -/1500 | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-24S12AC | 300 | -/9-40 | -/1500 | 89 | 61.0*57.9*12.7 | - | ||||
-/9-40 | -/1500 | 61.0*57.9*12.7 | ||||||||
ZBD300-24S15N-H | 300 | -/9-40 | -/1500 | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-24S15C-H | 300 | -/9-40 | -/1500 | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-24S15N | 300 | -/9-40 | -/1500 | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-24S15C | 300 | -/9-40 | -/1500 | 89 | 61.0*57.9*12.7 | - | ||||
-/9-36 | -/1500 | 61.0*57.9*12.7 | ||||||||
ZBD300-24S24AN-H | 300 | -/9-36 | -/1500 | 90 | 61.0*57.9*12.7 | - | ||||
ZBD300-24S24AC-H | 300 | -/9-36 | -/1500 | 90 | 61.0*57.9*12.7 | - | ||||
ZBD300-24S24AN | 300 | -/9-36 | -/1500 | 90 | 61.0*57.9*12.7 | - | ||||
ZBD300-24S24AC | 300 | -/9-36 | -/1500 | 90 | 61.0*57.9*12.7 | - | ||||
-/18-36 | -/1500 | 61.0*57.9*12.7 | ||||||||
ZBD300-24S28N-H | 300 | -/18-36 | -/1500 | 90 | 61.0*57.9*12.7 | - | ||||
ZBD300-24S28C-H | 300 | -/18-36 | -/1500 | 90 | 61.0*57.9*12.7 | - | ||||
ZBD300-24S28N | 300 | -/18-36 | -/1500 | 90 | 61.0*57.9*12.7 | - | ||||
ZBD300-24S28C | 300 | -/18-36 | -/1500 | 90 | 61.0*57.9*12.7 | - | ||||
-/18-36 | -/1500 | 61.0*57.9*12.7 | ||||||||
ZBD300-24S36N-H | 300 | -/18-36 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD300-24S36C-H | 300 | -/18-36 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD300-24S36N | 300 | -/18-36 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD300-24S36C | 300 | -/18-36 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
-/36-75 | -/1500 | 61.0*57.9*12.7 | ||||||||
ZBD300-48S24N-H | 300 | -/36-75 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD300-48S24C-H | 300 | -/36-75 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD300-48S24N | 300 | -/36-75 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD300-48S24C | 300 | -/36-75 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
-/36-75 | -/1500 | 61.0*57.9*12.7 | ||||||||
ZBD300-48S48N-H | 300 | -/36-75 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD300-48S48C-H | 300 | -/36-75 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD300-48S48N | 300 | -/36-75 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD300-48S48C | 300 | -/36-75 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
-/18-75 | -/1500 | 61.0*57.9*12.7 | ||||||||
ZBD300-48S48AN-H | 300 | -/18-75 | -/1500 | 92 | 61.0*57.9*12.7 | - | ||||
ZBD300-48S48AC-H | 300 | -/18-75 | -/1500 | 92 | 61.0*57.9*12.7 | - | ||||
ZBD300-48S48AN | 300 | -/18-75 | -/1500 | 92 | 61.0*57.9*12.7 | - | ||||
ZBD300-48S48AC | 300 | -/18-75 | -/1500 | 92 | 61.0*57.9*12.7 | - | ||||
-/43-160 | 3000/- | 61.0*57.9*12.7 | ||||||||
ZBD300-110S12N-H | 300 | -/43-160 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-110S12C-H | 300 | -/43-160 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-110S12N | 300 | -/43-160 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-110S12C | 300 | -/43-160 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
-/43-160 | 3000/- | 61.0*57.9*12.7 | ||||||||
ZBD300-110S14N-H | 300 | -/43-160 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-110S14C-H | 300 | -/43-160 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-110S14N | 300 | -/43-160 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-110S14C | 300 | -/43-160 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
-/43-160 | 3000/- | 61.0*57.9*12.7 | ||||||||
ZBD300-110S15N-H | 300 | -/43-160 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-110S15C-H | 300 | -/43-160 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-110S15N | 300 | -/43-160 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-110S15C | 300 | -/43-160 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
-/43-160 | 3000/- | 61.0*57.9*12.7 | ||||||||
ZBD300-110S24AN-H | 300 | -/43-160 | 3000/- | 91 | 61.0*57.9*12.7 | - | ||||
ZBD300-110S24AC-H | 300 | -/43-160 | 3000/- | 91 | 61.0*57.9*12.7 | - | ||||
ZBD300-110S24AN | 300 | -/43-160 | 3000/- | 91 | 61.0*57.9*12.7 | - | ||||
ZBD300-110S24AC | 300 | -/43-160 | 3000/- | 91 | 61.0*57.9*12.7 | - | ||||
-/43-160 | 3000/- | 61.0*57.9*12.7 | ||||||||
ZBD300-110S28N-H | 300 | -/43-160 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
ZBD300-110S28C-H | 300 | -/43-160 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
ZBD300-110S28N | 300 | -/43-160 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
ZBD300-110S28C | 300 | -/43-160 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
-/43-160 | 3000/- | 61.0*57.9*12.7 | ||||||||
ZBD300-110S36N-H | 300 | -/43-160 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
ZBD300-110S36C-H | 300 | -/43-160 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
ZBD300-110S36N | 300 | -/43-160 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
ZBD300-110S36C | 300 | -/43-160 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
-/185-400 | 3000/- | 61.0*57.9*12.7 | ||||||||
ZBD300-280S28CN-H | 300 | -/185-400 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-280S28CC-H | 300 | -/185-400 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-280S28CN | 300 | -/185-400 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-280S28CC | 300 | -/185-400 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
-/185-400 | 3000/- | 61.0*57.9*12.7 | ||||||||
ZBD300-280S48CN-H | 300 | -/185-400 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
ZBD300-280S48CC-H | 300 | -/185-400 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
ZBD300-280S48CN | 300 | -/185-400 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
ZBD300-280S48CC | 300 | -/185-400 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
-/300-900 | 3000/- | 61.0*57.9*12.7 | ||||||||
ZBD300-540S24N-H | 300 | -/300-900 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-540S24C-H | 300 | -/300-900 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-540S24N | 300 | -/300-900 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-540S24C | 300 | -/300-900 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
-/300-1200 | 3000/- | 61.0*57.9*12.7 | ||||||||
ZBD300-750S24AN-H | 300 | -/300-1200 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-750S24AC-H | 300 | -/300-1200 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-750S24AN | 300 | -/300-1200 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
ZBD300-750S24AC | 300 | -/300-1200 | 3000/- | 89 | 61.0*57.9*12.7 | - | ||||
-/16-40 | -/1500 | 61.0*57.9*12.7 | ||||||||
ZBD350-24S36N-H | 350 | -/16-40 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD350-24S36C-H | 350 | -/16-40 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD350-24S36N | 350 | -/16-40 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD350-24S36C | 350 | -/16-40 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
-/16-36 | -/1500 | 61.0*57.9*12.7 | ||||||||
ZBD350-24S48N-H | 350 | -/16-36 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD350-24S48C-H | 350 | -/16-36 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD350-24S48N | 350 | -/16-36 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD350-24S48C | 350 | -/16-36 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
-/36-75 | -/1500 | 61.0*57.9*12.7 | ||||||||
ZBD350-48S12N-H | 350 | -/36-75 | -/1500 | 90 | 61.0*57.9*12.7 | - | ||||
ZBD350-48S12C-H | 350 | -/36-75 | -/1500 | 90 | 61.0*57.9*12.7 | - | ||||
ZBD350-48S12N | 350 | -/36-75 | -/1500 | 90 | 61.0*57.9*12.7 | - | ||||
ZBD350-48S12C | 350 | -/36-75 | -/1500 | 90 | 61.0*57.9*12.7 | - | ||||
-/36-75 | -/1500 | 61.0*57.9*12.7 | ||||||||
ZBD350-48S28N-H | 350 | -/36-75 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD350-48S28C-H | 350 | -/36-75 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD350-48S28N | 350 | -/36-75 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
ZBD350-48S28C | 350 | -/36-75 | -/1500 | 91 | 61.0*57.9*12.7 | - | ||||
-/36-100 | -/1500 | 61.0*57.9*12.7 | ||||||||
ZBD400-48S24N-H | 400 | -/36-100 | -/1500 | 92 | 61.0*57.9*12.7 | - | ||||
ZBD400-48S24C-H | 400 | -/36-100 | -/1500 | 92 | 61.0*57.9*12.7 | - | ||||
ZBD400-48S24N | 400 | -/36-100 | -/1500 | 92 | 61.0*57.9*12.7 | - | ||||
ZBD400-48S24C | 400 | -/36-100 | -/1500 | 92 | 61.0*57.9*12.7 | - | ||||
-/43-160 | 3000/- | 61.0*57.9*12.7 | ||||||||
ZBD400-110S28AN-H | 400 | -/43-160 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
ZBD400-110S28AC-H | 400 | -/43-160 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
ZBD400-110S28AN | 400 | -/43-160 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
ZBD400-110S28AC | 400 | -/43-160 | 3000/- | 90 | 61.0*57.9*12.7 | - | ||||
-/66-160 | 3000/- | 61.0*57.9*12.7 | ||||||||
ZBD400-110S48N-H | 400 | -/66-160 | 3000/- | 92 | 61.0*57.9*12.7 | - | ||||
ZBD400-110S48C-H | 400 | -/66-160 | 3000/- | 92 | 61.0*57.9*12.7 | - | ||||
ZBD400-110S48N | 400 | -/66-160 | 3000/- | 92 | 61.0*57.9*12.7 | - | ||||
ZBD400-110S48C | 400 | -/66-160 | 3000/- | 92 | 61.0*57.9*12.7 | - | ||||
-/50-160 | 3000/- | 61*57.9*12.7 | ||||||||
ZBD400-110S24AN-H | 400 | -/50-160 | 3000/- | 90 | 61*57.9*12.7 | - | ||||
ZBD400-110S24AC-H | 400 | -/50-160 | 3000/- | 90 | 61*57.9*12.7 | - | ||||
ZBD400-110S24AN | 400 | -/50-160 | 3000/- | 90 | 61*57.9*12.7 | - | ||||
ZBD400-110S24Ac | 400 | -/50-160 | 3000/- | 90 | 61*57.9*12.7 | - | ||||
-/36-75 | -/1500 | 61.0*57.9*12.7 | ||||||||
ZBD400-48S28N-H | 400 | -/36-75 | -/1500 | 92 | 61.0*57.9*12.7 | - | ||||
ZBD400-48S28C-H | 400 | -/36-75 | -/1500 | 92 | 61.0*57.9*12.7 | - | ||||
ZBD400-48S28N | 400 | -/36-75 | -/1500 | 92 | 61.0*57.9*12.7 | - | ||||
ZBD400-48S28C | 400 | -/36-75 | -/1500 | 92 | 61.0*57.9*12.7 | - |
